Austin A.F.T.3 (Osprey)

History

By 1918, when the First World War began, the search for a viable successor to the classic Sopwith Camel biplane had begun. The camel appeared in June 1917, and by wartime standards, it had a long life in the face of ever-changing air combat techniques and tactics. The Austin Osprey was a single-seat triplane that was developed hoping to follow an established design, but ultimately lost out to the Sopwith Snipers, nearly 500 of which were produced from 1918.

Only one Osprey prototype was built by the Austin Motor Company, and the design was quickly forgotten.

The original request was made by the British authorities in 1917 (norm A.1.A) and called for a single seat double gun mount to replace the ancient camel. At this point in the war, the Austin Motor Company, like the rest of British industry, was already helping the war by producing aircraft designs from other companies to meet demand.

When the specification came out, Austin decided to try to design and develop a suitable fighter. The result was the A.F.T. 3 "Osprey", of which three prototypes were ordered.

Interestingly, the engineers opted for a three-wing arrangement instead of the standard two-wing common to many fighter jets of the era.

Overall, Osprey employs a proven structure from the inside out, as well as traditional design techniques that barely stand out from the competition. Dimensions include a length of 17.6 feet, a wingspan of 23 feet and a height of 18.7 feet. The kerb weight is 500kg and the loaded weight is 860kg. Power is provided by a nose-mounted 230 hp Bentley BR2 series rotary engine driving a two-bladed wooden propeller.

Performance specs include a top speed of 119 mph, a service ceiling of 19,000 feet and up to three hours of air endurance. The three wing arrangements are all of equal span, with forward sloping and parallel strut works.

Armament is usually a pairing of 2 x. The 303 Vickers machine gun is located in a fixed forward firing position above the nose and fires synchronously through rotating propeller blades. Another interesting feature of the Osprey is the installation of a third machine gun, a Lewis machine gun mounted in the center section of the central wing assembly.

Furthermore, this setup is trainable to a certain extent, but its flexibility does not contribute much.

In February 1918, as the war raged, the first test flight of the Osprey prototype took place over the next few weeks. In its current form, the Osprey can't compete with a fast twin-blade sniper (using the same engine) in terms of performance.

Its three-blade layout created drag while providing increased agility at a time when speed was the norm in fighter jets. As a result, the Osprey never passed the prototype stage, and its two remaining prototypes were never built.
