Beechcraft Bonanza

1947 COLD WAR MODERN AIRCRAFT

Story of Beechcraft Bonanza

Beechcraft 'Bonanza' is one of the world's greatest commercial aviation success stories after World War II. With more than 17,000 produced, the aircraft remains a fixture in the general aviation (GA) market. The first flight was recorded on December 22, 1945, and the type is still widely used today in both civilian and military fields.

Military operators include Haiti, Iran, Indonesia, Cote d'Ivoire, Mexico, Netherlands, Nicaragua, Portugal, Spain, Thailand and the United States.

The

Bonanza's design has a very traditional look: the engine is traditionally mounted in the nose, and the pilot and one-sided passenger have a double side-by-side seating arrangement. More people can be accommodated in the rear of the cabin. Wing main aircraft are straight appendages mounted low on the sides of the fuselage.

The tail is the main feature of the Bonanza, one shape is a traditional/traditional single vertical tail with a low set plane, and the other is a V-tail unit with the vertical tail sloped outward (no horizontal plane). Due to the many accidents involved, this version has been dubbed "The Doctor Killer".

Due to its wide range of global operators (and long tenure), the Bonanza series consists of several variants. The large subgroup of Model 33 "Debonair"/"Bonanza" alone has 14 markers, while the Model 35 Bonanza that follows contains no less than 19 private labels. The Type 36 was followed by nine of its own, including the QU-22 for USAF service. The QU-22 Pave Hawk, a variant of the Type 36/A36, served the US Air Force during the Vietnam War (1955-1975) as a signal relay platform and was equipped with an electronic surveillance system.

This one also differs in that it is powered by a turbocharged Continental GTSIO-520-G series engine with reduced noise.

The Type 40 appeared in 1948 as an experimental form. The Defense Industry Organization of Iran (DIO) illegally remanufactured the F33 model as the basis for its localized "Paraatsu".

The 2011 G36 production form accommodates a pilot and up to five passengers. It has an overall length of 27.5 feet, a wingspan of 33.5 feet and a height of 8.6 feet. Curb weight is 2,515 lbs and MTOW is 3,650 lbs.

Power comes from a 300-horsepower Continental IO-550-B engine that drives a Hartzell-brand three-blade propeller unit in the nose. Cruise speeds reach 203 mph, range (ferry) is up to 1,070 miles, and service is capped at 18,500 feet. The climb rate is 1,230 feet per minute.
