HMS Daring (D32)

HMS Bold (D32) History

HMS Daring (D43) represents the capital ships of the Royal Navy's Six-class surface warships - widely regarded as the most powerful destroyer class in the world. The ship, part of the modern Type 45, serves the fleet as a guided missile destroyer, primarily providing air defenses against incoming threats such as aircraft or cruise missiles. As a result, HMS Daring is comparable in mission range and range to the U.S. Navy's Arleigh Burke-class guided-missile destroyers, capable of countering all types of surface and air threats as needed.

The HMS Daring was originally ordered in December 2000 and laid on March 23, 2003 by a BAe Systems naval vessel at Dock 1061. Commissioned on July 23, 2009.

She is currently active in the British Fleet, fighting under the motto "Splendide Audax" ("Fine Daring"), and is homeported at HMNB Portsmouth in the south of England.

Navy destroyers are purpose-built fast warships with excellent seafaring qualities and inherent maneuverability. Her weapon is a multitasking approach to both attack and defense, and the type can operate in the ranks of a sailing fleet or independently of it when tracking perimeter threats such as looting enemy submarines. The HMS Daring, in particular, has a range of 8,800 tonnes and is powered by an integrated electric propulsion system consisting of a gas turbine, diesel and generator.

The vessel is also equipped with an array of sensors and processing systems that allow it to track, identify and engage various types of targets from a distance.

The design of HSM Daring is traditional in a modern sense. The bow is sharp, extending to the stern to widen amidships, and the stern is angular. The deck is intentionally featureless to encourage a "stealth" quality on the high seas. As a result, the sides of its structure are covered with a long sloping plate. The deck guns are located in the long bow, and the vertical launch rocket compartment is directly aft.

The main structure containing the bridge (identifiable by its large rectangular windows) begins behind the launch unit. Aft of the bridge section is a pyramid-shaped mast housing with a radome on top (this is Sampson's surveillance and fire control system). The pyramid is flanked by two satellite communication domes, which stand on protruding shelves. The structure then plummeted into a closed funnel, exhausting the engine layout, with a distinctly angular top. There is a distinct gap between the front and rear of the superstructure, while the midship stern contains a mast and then another pyramid-shaped structure covered by an air search radar system.

The hangar is at the back of this structure, while the helipad is at the very end of the ship. Overall, HMS Daring promotes an extremely clean profile match for modern surface combatants.

HMS Daring is propelled by an Integrated Electric Propulsion (IEP) system, fed to twin axles. The arrangement uses 2 Rolls-Royce WR-21 series gas turbine engines (28,800 hp each) and 2 Wartsila 12V200 diesel generator sets (2,700 hp each) and 2 Converteam electric motors (27,000 hp).

The maximum speed is 30 knots and the range is 7,000 nautical miles under ideal conditions. The IEP arrangement facilitates the design as no mechanical transmission is required for either axis.

Gas turbines and diesel generators feed frequency converters mounted in front of the electric motors on each propeller shaft. Thus, ships can use low power approaches during normal cruise and high power approaches during full flight maneuvers, since there is always one form of propulsion (or both) that uses stealth and maintenance/cost advantages that make this configuration Increasingly popular among naval battleships.

The ship is well equipped (the "destroyer" classification says it all). As a guided missile destroyer, HMS Daring is equipped with a 48-cell Vertical Launch System (VLS) containing 48 surface-to-air missiles.

Depending on the type of missile in storage (Aster 15 or Aster 30 series or a combination of both), these weapons can hit targets at ranges from 2 to 120 km. The firing unit is supported by more traditional deck gun equipment - a 4.5-inch rapid-fire BAE Systems Mk 8 Mod 1 series gun - capable of engaging ground targets from a distance or providing littoral bombardment.

The gun is a single-barreled system housed in a transversely armored hull, limited only by the superstructure aft of the VLS, HMS Daring installed an additional 2 x 30mm gun assembly and 2 x 20mm Phalanx Close Combat Weapons Systems (CIWS) , ready for an aerial melee attack If the target passes through this defense network, the crew can deploy 2 Minigun systems as a final layer of defense. Up to 6 x 7.62mm general purpose machine guns are mounted around the ship to prevent extreme close range.

Notably, HMS Daring is also configured to use a pair of AGM-84 Harpoon anti-ship missile launchers (quad launchers), as well as the proven BGM-109 Tomahawk series cruise missiles, HMS Daring's props are usually positioned to attack enemy fighter planes, bombers, cruise missiles, enemy warships and submarines with equal lethality.

In addition to her physical weapons, HMS Daring also uses her electronic devices to gain an advantage in a given fight. Sensors include the SAMPSON Multifunction Air Tracking Radar System and the BAe/Thales S1850M Series Electronic Support Measures (ESM) fully digital 3D surveillance radar.

Raytheon supplied the ship's I and E/F band radar systems, while Ultra Electronics supplied the electro-optical gun control system (EOGCS), radar tracking kit and MFS-7000 series sonar system. HMS Daring is also equipped with countermeasures such as the UAT 16 arrangement, Surface Ship Torpedo Defense (SSTD) kit and Airborne Sys IDS300 decoy system.

All Type 45 ships will receive the advanced Thales ESM system in early 2012.

With the helipad at the rear (and enclosed hangar facility), HMS Daring can launch and recover 1 or 2 Westland Lynx HMA 8 series naval helicopters or 1 Westland Merlin HM 1 medium transport helicopter. Both types can be equipped with anti-ship and anti-submarine measures to provide an over-the-horizon approach to potential threats.

The hangar facility allows repairs and maintenance at sea and the area is fully protected.

Once launched, HMS Daring will be tasked with patrolling the Red Sea and Gulf of Aden region in search of Somali pirates - a growing threat. The ship became part of an international presence in East African waters to deter threats to merchant ships in the region (oil was a major concern), so the ship and crew worked in tandem with Allied navies.

Apart from this operation, the history of HMS Daring has not been fully written.
