USS Conyngham (DDG-17)

History of USS Cunningham (DDG-17)

After World War II (1939-1945), as service shifted from limited, coast-facing service to the Soviet Navy's threat to Western prospects Significantly add a defensive force that can expand its forces around the world - in large part through substantial investments in surface and submarine fleets. This prompted the U.S.-led West to take on its potential foe, and the Charles F. Adams-class guided-missile destroyer was born.

These 3,300-ton ships, 29 in total, 23 of which are in service with the US Navy and 3 each delivered to West Germany and Australia, are offshoots of the former Forrest Sherman-class ships, whose battlefield roles have been rewritten as guided-missile destroyers - added The focus on missile weapons, which became the "Tatar" surface-to-air missile (SAM) system.

USS Conyngham (DDG-17) is considered a member of this class, the battleship was launched on 1 May 1961, launched on 18 May 1962, and commissioned with the USN on 13 July 1963 (Battle motto "Ready to Serve"). The ship served with the U.S.

Navy until October 30, 1990, but was stripped of its use and eventually sold for scrap.

Named after the Irish-American continental naval revolutionary Gustavus Conyngham (1747-1819), the aircraft carrier USS Conningham followed Adams-class design standards, displacing 3,300 tons at standard load and at full load Displacement is 4,525 tons, length is 437 feet with a beam of 47 feet and a draft of 15 feet.

The

Adams class was the last commissioned vessel powered by steam, equipped with 2 General Electric steam turbines rated at 70,000 hp. These are powered by 4 x Combustion Engineering boiler units and power 2 x axles under the stern.

Under ideal conditions, Cunningham is capable of reaching speeds of up to 33 knots and a range of up to 4,500 nautical miles, which gives her blue water capabilities.

There are 354 units on board. The ship was equipped with various sensors, processing and communication systems of the time, including sonar, 3D air search radar, surface search radar and fire control assistant.

Armament includes a Mk 13 single-arm rocket launcher and 2 x 5"/24 caliber Mark 42 deck guns. Also 1 x RUR-5 anti-submarine rocket (ASROC) launcher and w x Mark 32 triple torpedo tubes.

Cunningham's career has taken her around the world on patrols and goodwill stops in the Mediterranean, Middle East and Caribbean. Notable operations include Libya (1982), Lebanon (1983) and Grenada (1983).

Overall, she will receive four Combat Effectiveness (E) awards for actions dedicated to protecting U.S. interests.

In May 1990, a fire broke out on board, killing one officer and injuring 18 others. The damage was so extensive that the ship, which had just finished maintenance/overhaul, was not repaired and salvaged. This last event led to their official retirement.

The cause of the fire was the improper installation of the heating oil filter, which caused the heating oil to catch fire.

Specification

Basic

Year of Service

1963

Origins

United States

Status

stop service

Destroyed, scrapped.

supplement

354

staff

Class information

Class

Charles F. Adams class

Class Size

23

ships

Class

USS Charles F. Adams (DDG-2); USS John King (DDG-3); USS Lawrence (DDG-4); USS Claude V Ricketts (DDG-5); USS Barney (DDG-6) ; USS Henry B Wilson (DDG-7); USS Lynd McCormick (DDG-8); USS Tower (DDG-9); USS Sampson (DDG-10); USS Seller (DDG-11) USS Robinson (DDG-12); USS Hall (DDG-13); USS Buchanan (DDG-14); USS Berkeley (DDG-15); USS Josef Strauss (DDG-16) ; USS Conningham (DDG-17); USS Symes (DDG-18); USS Tatnall (DDG-19); USS Goldsborough (DDG-20); USS Cochran (DDG-21) USS Benjamin Stoddt (DDG-22); USS Richard E Bird (DDG-23); USS Waddell (DDG-24)

Operators

United States

Characters

Sea Bombing

Maritime bombardment/attack of surface targets/areas primarily through ship-based ballistic weapons.

Land Assault

Littoral attacks against surface targets primarily through ship-based missiles/missile weapons.

Sea Patrol

Active patrolling of critical waterways and sea areas; also serves as a local deterrent against air and maritime threats.

Airspace Denial/Deterrence

Neutralization or deterrence of flying elements by airborne missile weapon ballistics.

Fleet Support

Provide support (fire or materiel) to major surface fleets in blue water environments.

Dimensions and Weight

Length

437. 0 feet

133.20m

Ray

47. 0 feet

14.33m

Draft

15. 0 feet

4.57m

Shift

3,275 t

Power and Performance

Installed Power:

4 x Babcock & Wilcox Boiler Units 2 x Axle Rear for 2 x General Electric 70,000hp Steam Turbines.

Surface Velocity

33.0 nodes

(38.0km/h)

Area

4,501nm

(5,180 miles | 8,336 kilometers)

Weapon

2 x 5" (127 mm) /54 caliber Mark 42 deck gun with turret. 1 x Mk 13 Surface-to-Air Rocket Launcher (SAM) for RIM-24 Tartar / RIM -66 Standard-SM-1 Series. 1 x RUR-5 Anti-Submarine Rocket (ASROC) Launcher. 2 x 324 mm Marck 32 Triple Torpedo Tubes.

Aircraft

None.
